CNC Precision Internal Grinding Machine IGM2TNCⅢ

SERIES line-up

IGM2TNCⅢ・IGM2TNCⅢ-3・IGM2TNCⅢ-4

Concept

IGM2TNCIII : Max. swivel 15 deg. for workspindle base in 1000mm long workpiece IGM2TNCIII-3 or 4 : Max. workpiece length 1000 - 2000mm Large size internal grinder (need to discuss specification)

Feature

  • Supports up to eight continuous processes with conversational software, allowing easy setup of reverse table position and infeed starting position through either the teaching method or manual key input.
  • Enables adjustment of workpiece length by shifting the work spindle base left or right. Additionally, features such as interrupt dressing, cycle stop, and infeed return can be executed during the cycle for added flexibility.
  • Offers optional functionality for face grinding of long workpieces, enhancing the machine's versatility.

Uses of the CNC Precision Internal Grinding Machine IGM2TNCⅢ


  • The IGM2TNCⅢ is a versatile CNC precision internal grinding machine designed for high-performance internal grinding applications. Below are its key uses across various industries:

    1. High-Precision Internal Grinding

    • Suitable for grinding the inner diameters of cylindrical and conical components with exceptional accuracy.
    • Commonly used in applications demanding tight tolerances, such as bearing races, gear shafts, and spindles.

    2. Multi-Step Grinding

    • Performs complex, multi-step grinding processes in a single setup, saving time and improving precision.
    • Ideal for components requiring different diameters or profiles on the same workpiece.

    3. Aerospace Component Manufacturing

    • Used in grinding high-precision parts for aerospace applications, such as turbine shafts, jet engine components, and hydraulic system components.

    4. Automotive Industry Applications

    • Supports grinding of components like fuel injection nozzles, engine cylinders, and clutch mechanisms, ensuring optimal performance and durability.

    5. Tool and Die Production

    • Excels in producing high-precision tools and dies with intricate internal profiles.
    • Utilized in industries requiring specialized tooling for molding and cutting.

    6. Medical Device Manufacturing

    • Ideal for creating components like surgical instruments, dental tools, and orthopedic implants, requiring smooth finishes and precise dimensions.

    7. Research and Prototyping

    • Frequently used in R&D facilities for creating prototypes and testing new designs with precise specifications.

    8. Customizable Grinding for Long Workpieces

    • With its optional face grinding capability, it is suitable for long workpieces, such as large cylinders or shafts, offering flexibility for specialized tasks.

    9. Efficient Dressing and Maintenance Options

    • Features interrupt dressing, infeed return, and cycle stop, enabling efficient operation and ensuring consistent grinding quality over extended production runs.

    10. Production Line Integration

    • Easily integrates into automated production lines, supporting high-volume manufacturing environments.
    The IGM2TNCⅢ is a reliable solution for industries requiring exceptional precision, versatility, and efficiency in internal grinding applications.
