Horizontal bandsaw HBE411A Dynamic
The BEHRINGER HBE411A Dynamic automatic band saw is engineered for cost-effective operation in industrial and steel trading environments. It delivers efficient cutting performance with minimal deviations, suitable for a variety of metals and plastics, whether easy or challenging to work with. This band saw accommodates a diverse selection of materials, including profiles, tubes, and solid stock. Its spacious full enclosure ensures maximum safety while allowing easy access for users. Additionally, its low energy usage promotes environmentally friendly production practices.
-
Features of the horizontal bandsaw HBE411A Dynamic
- Cast iron band guiding parts
Manufactured by Behringer, these tools feature vibration damping at the cutting edge, which enhances their longevity.
- Auto-Feed-Control
Choosing materials from a comprehensive database, the AFC autonomously determines the ideal settings for saw feed and cutting speed.
- Energy efficient
By incorporating advanced drives and a unique hydraulic system, energy usage is lowered by about 30% compared to the earlier model.
- Precision portal-design guide system
The integration of a sturdy, low-vibration saw frame with a linear guide system in a portal configuration guarantees optimal band sawing performance and extended durability.
- Electrically driven chip brush
Equipped with a Behringer quick-change system, this device allows for effortless brush replacements without the need for tools. The unique engagement angle safeguards the teeth of the saw blade.
- Servo down feed system
The feeding of the saw is accomplished using a ball screw and servo motor, leading to notably reduced idle times and enhanced accuracy in saw feeds. The benefit for you: improved cutting efficiency and extended lifespan of the band!
- Automatic guide arm
Achieve the best sawing performance without adjustments, even when dealing with varying material sizes.
- Easy to use
All functions of the automatic band saw can be operated swiftly and effortlessly through touch controls.
- Double clamping vice
ensures consistent performance, particularly during the cutting of bundles or individual pieces. The band saw's clamping jaws are positioned at both entry and exit points, securely holding the raw material as well as the completed cut.
-
Technical data horizontal bandsaw HBE411A Dynamic
- Cutting range
| Cutting range 90° round | 16.1 in |
| Cutting range 90° flat | 20.1 x 16.1 in |
| Smallest dimension to be sawn round | 0.4 in |
| Smallest dimension to be sawn flat | 0.4 x 0.3 in |
- Performance characteristics
| Feeding length single stroke | 25.6 in |
| Drive power | 5.1 hp |
| Blade speed | 33 - 360 fpm |
| Saw blade dimensions | 225.6 x 1-1/2 x 0.05 in |
| Rest piece length in automatic operation | 3.1 in |
| Total power | 6.7 hp |
| Saw feed | servo-feed via ball screw |
| Material feed | ball screw |
| Material clamping | hydraulic |
| Saw blade cleaning | electrically driven chip brush |
- Dimensions and weight
| Length | 78.7 in |
| Width | 112.2 in |
| Height | 87.4 in |
| Weight | 7054.8 lbs |
| Material support height | 31.5 in |
-
Applications of the Horizontal Bandsaw HBE411A Dynamic
1. Metal Profile Cutting
Cuts a wide range of materials, including steel, aluminum, and alloys. Suitable for processing metal bars, tubes, and profiles with precision.2. Production and Manufacturing
Ideal for high-volume, repetitive cutting tasks in production lines. Ensures consistent quality and efficiency in manufacturing processes.3. Construction and Structural Fabrication
- Prepares structural elements such as beams, channels, and angles.
- Used in infrastructure and building projects requiring precision cuts.
4. Automotive and Aerospace Industries
Produces components for vehicles and aircraft with high accuracy. Handles various materials, from lightweight alloys to heavy-duty steel.5. Tool and Machinery Fabrication
Cuts raw materials for making tools, equipment, and industrial machinery. Essential for applications requiring exact specifications.6. Prototyping and Custom Projects
Supports the creation of prototypes and custom metal parts. Allows flexibility for unique designs and specialized requirements.7. Maintenance and Repairs
Assists in fabricating spare parts for maintenance and repair tasks. Suitable for workshops needing quick and precise material cutting.8. Heavy-Duty Cutting
Handles thick, hard, and dense materials efficiently. Designed for challenging applications in industrial settings.9. Energy-Efficient and Automated Operations
Supports automatic feed control and optimized cutting pressure. Reduces material waste and improves operational efficiency.-
